Technical data
| Number of effective cutting edges on the circumference | 10 |
| Mounting diameter on machine side mm C3 DCONMS | 12 |
| Machine-side admission form | 1835 B-stock |
| Coating H5 COATN | uncoated |
| DIN Norm | DIN 1833 D |
| fz mm tooth | 0,060-0,100 |
| Total length mm | 67 |
| Manufacturer item number shop | 169361 45X25,0 |
| Material | HSS-Co |
| Profile angle | 45 |
| Cutting diameter mm A1 DC | 25 |
| Cutting length max mm | 6.3 |
| A1 Cutting diameter mm | 25 |
| B2 B6 Cutting length max mm | 6 |
| B3 B4 B5 Total length mm | 67 |
| C12 Mounting form on the machine side | 1835 B-stock |
| C3 Mounting diameter on machine side mm | 12 |
| F21 Number of effective cutting edges on the circumference | 10 |
| G5 Profile angle | 45 |
