Tabular product data
| Area of application material to be processed | P |
| Flank angle | 60 |
| Form | Hexagon |
| Lapped | No |
| Total length mm | 7 |
| Thread type | M |
| Nominal thread diameter metric A21 | M6 |
| Thread pitch mm A3 | 1 |
| Manufacturer item number shop | 120418 |
| Body diameter mm A7 | 18 |
| Thread norm | DIN 13 |
| Standard of the die | DIN 382 |
| Surface | HSS |
| Sectional view | No |
| Cutting direction | right |
| Tolerance field | 6g |
| A21 Thread nominal diameter metric | M6 |
| A3 Thread pitch mm | 1 |
| A7 Body diameter mm | 18 |
| B3 B4 B5 Total length mm | 7 |
| F1 Cutting Direction | right |
